| Protocol |
SSCNET III/H (Mitsubishi Network Protocol), 0.888ms Scan time |
| Communication port |
2 port(Up to 16 slaves can be installed on each port) |
| Connector |
FO x 2ea, 2 Seperated NET, Max 16 Nodes on Each NET. |
| Control Slave |
32 Slave |
| Control Axes |
16 Axes / 32 Axes |
| Transmission speed |
150 Mbps |
| Transmission bytes |
52 Bytes |
| BUS Interface |
PCI 2.2 Memory access, Universal Voltage I/O |
| Network connection |
F07PN(Fiber-optic)
Inter-node : Max 20m, Total : Max 320m : Standard
Inter-node : Max 100m, Total : Max 1.6km : Long-distance |
| Bus Interface |
PCI 2.2, Memory Access |
| Connector |
FO x 2EA, 2 Seperated DET, Max 16 Nodes on Each NET. |
| Power Input |
DC 5V, Max. 1.6A |
| Exterior dimension of product |
174.63 x 106 [mm] |
